Mould Processing Foundry Pattern Machine

TigerTec Mould Processing Foundry Pattern Machine is designed with flexibility in mind and you can use this model for any CNC project in the foundry industry. We use stronger parts for the whole machine to ensure you can get higher accuracy and speed but at an affordable price. We also offer some options for these machines, different power of spindles, motors, and special sizes as requested.

product details

product description

description1

description2

TECHNICAL PARAMETERS

Model No	Process Area			Accuracy	Weight	Foot Print(W×L×H）
Model No	X	Y	Z	Accuracy	Weight	Foot Print(W×L×H）
PT510	1500mm	3000mm	800mm	±0.03mm/m	7500KGS	3400mm	4570mm	2500mm
PT510	59.1″	118.1″	31.5″	±0.03mm/m	7500KGS	133.9″	179.9″	99″
PT710	2000mm	3000mm	800mm	±0.03mm/m	8000KGS	3400mm	4700mm	2500mm
PT710	78.7″	118.1″	31.5″	±0.03mm/m	8000KGS	133.9″	185″	99″
PT712	2000mm	4000mm	800mm	±0.03mm/m	8500KGS	3400mm	5700mm	2500mm
PT712	78.7″	157.5″	31.5″	±0.03mm/m	8500KGS	133.9″	224.4″	99″

PRODUCT Introduction

Product Description

Outstanding Features

High precision and reliability over time.

High-speed absolute Servo Drives on all axes.

Rack and Pinon on X and Y using Planetary Gear Boxes, Ball Screw on Z-axis

Installation of linear rail for X-Y-axis with metal block is designed to increase precision and reliability standards for the execution of machining operations.

A wide range of table sizes available covers all the standard panel sizes in the nesting industry and customers can choose the most suitable machine for their needs.

Strength

Heavy duty welded steel structure guarantees solidity and absence of vibration, for consistent product quality over time.

Solid Aluminum table

T-slot solid Aluminum table with T-Nuts and Clamps included.

Motors and Drives (SIEMENS)

Absolute Servo with high precision Planetary Reducer on all axis.

HSD ATC Spindle

High power motorized spindle can easily process all kinds of materials

PT 2030 selects Italian HSD air-cooled spindle ES951 9.5KW. Choose from manual, quick-release, high-power and high-speed spindles for optimum processing of rigid sheet materials.

Quality power reliability precision, available with 9.5kw-18kw Automatic Toolchange Spindle.
